About
NATS-S3-Connector bridges NATS Jetstream to S3 object storage, enabling long-term retention and replay of messages. The application provides bidirectional flow, storing messages from NATS to S3 and loading them back when needed. Through store and load jobs, messages are compressed into chunks, tracked with metadata, and made available for replay at any point in time.
Design
NATS-S3-Connector operates on a two-tier storage model with Postgres serving as the metadata store and S3 providing long-term object storage for compressed message chunks.
.----------. .----------. .----------. .---------.
| NATS | | In-Memory| | Compress | | S3 |
| Jetstream+------>| Buffer +------>| & Batch +------>| Bucket |
'----------' '----------' '----+-----' '---------'
| | | |
| | | |
| Time elapsed or v |
| threshold reached .----------. |
| | Postgres | |
| | Chunk | |
| | Metadata | |
| '----------' |
| ^ |
| | |
| | |
| | |
.----------. .----------. .----+----. .---------.
| NATS | | Download | | Postgres| | S3 |
| Jetstream|<------+ & |<------+ Query |<------+ Bucket |
'----------' |Decompress| | Chunks | '---------'
'----------' '---------'
|
v
.----------.
| Mark |
| Deleted |
'----------'
Store jobs consume messages from NATS subjects and buffer them in memory. When time elapses or the buffer reaches configured thresholds (max bytes or max messages), the batch is compressed and uploaded to S3. Chunk metadata including bucket location, time ranges, message counts, and content hashes are persisted to Postgres for tracking and retrieval.
Load jobs query Postgres for chunks matching specified streams, subjects, and time ranges. Chunks are downloaded from S3, decompressed, and messages are published back into NATS. After successful loading, chunks are be marked as deleted or removed entirely from the metadata store.
The application is built in Rust with Axum handling HTTP requests and Tokio providing the async runtime. Connection pooling to Postgres is managed with bb8. The system exposes both an HTTP API and a CLI tool for managing jobs.
CLI
A formatted CLI is provided for managing store and load jobs alongside the HTTP API.
Store jobs:
nats3 store list
╭──────────────────────────────────────┬───────────────────────┬─────────┬────────────────────────┬────────────┬──────────┬────────────╮
│ id │ name │ status │ bucket │ stream │ consumer │ subject │
╞══════════════════════════════════════╪═══════════════════════╪═════════╪════════════════════════╪════════════╪══════════╪════════════╡
│ 24ce1555-b937-4321-9fa2-5e853a833690 │ test-store-1772065940 │ Running │ test-bucket-1772065940 │ test-input │ │ test.input │
╰──────────────────────────────────────┴───────────────────────┴─────────┴────────────────────────┴────────────┴──────────┴────────────╯
Load jobs:
nats3 load list
╭──────────────────────────────────────┬─────────┬────────────────────────┬─────────────┬───────────────┬──────────────┬───────────────╮
│ id │ status │ bucket │ read stream │ read consumer │ read subject │ write subject │
╞══════════════════════════════════════╪═════════╪════════════════════════╪═════════════╪═══════════════╪══════════════╪═══════════════╡
│ 70c8b4d7-020a-475e-bcb8-9dcd6b4213b1 │ Success │ test-bucket-1772065893 │ test-input │ │ test.input │ test.output │
╰──────────────────────────────────────┴─────────┴────────────────────────┴─────────────┴───────────────┴──────────────┴───────────────╯
Install with cargo install --path cli
API
Store jobs consume messages from NATS and upload them to S3 as compressed chunks.
Create via HTTP:
curl --header "Content-Type: application/json" \
--request POST \
--data '{
"name": "job-1",
"stream": "jobs",
"subject": "subject-1",
"bucket": "bucket-1"
}' \
http://localhost:8080/store/job
Or with the CLI:
nats3 store create \
--name job-1 \
--stream jobs \
--subject subject-1 \
--bucket bucket-1
Load jobs download chunks from S3 and publish messages back into NATS.
Create via HTTP:
curl --header "Content-Type: application/json" \
--request POST \
--data '{
"bucket": "bucket-1",
"read_stream": "jobs",
"read_subject": "subject-1",
"write_subject": "destination"
}' \
http://localhost:8080/load/job
Or with the CLI:
nats3 load create \
--bucket bucket-1 \
--read-stream jobs \
--read-subject subject-1 \
--write-subject destination
Metrics
Prometheus compatible metrics are exposed at /metrics. All metrics are prefixed with nats3.
# Job tracking
nats3_jobs_total{job_type="load",status="completed"} 1
nats3_jobs_current{job_type="store"} 1
# NATS throughput
nats3_nats_messages_total{direction="in"} 20
nats3_nats_messages_total{direction="out"} 20
nats3_nats_bytes_total{direction="in"} 20080
nats3_nats_bytes_total{direction="out"} 25868
# S3 operations
nats3_s3_objects_total{direction="out"} 3
nats3_s3_bytes_total{direction="in"} 25868
Deploying
There are prebuilt docker images at evanofslack/nats-s3-connector:latest
services:
nats3:
image: evanofslack/nats-s3-connector:latest
ports:
- 8080:8080
volumes:
- ./config.toml:/etc/nats3/config.toml
Build from source:
git clone https://github.com/evanofslack/nats-s3-connector
cd nats-s3-connector
cargo build
See the examples directory for full deployment configurations.
